Jewelry CAD design services and print-ready 3D files
Casting-ready STL and 3DM files built from your sketches, technical drawings or reference photographs - accurate to your measurements, with correct wall thickness and stone seating.
Trusted by Global Jewelry Brands, Casting Houses & Retailers
A file your caster can actually use
Plenty of 3D models look correct on screen and fail on the bench. Walls too thin to cast, stones that do not seat, prongs that will not hold, shanks that distort under polishing - these are manufacturing problems, not modelling problems, and they only show up once metal is involved.
We build for production. Wall thickness is checked against your casting process, stone seats are cut to the actual stone dimensions you supply, and prong geometry is set to hold rather than merely to look right in a render.
The same model then drives your marketing images, so the CAD file and the catalog photograph are guaranteed to agree.
From Client Reference to Casting CAD to Final Render
See how we transform a customer's raw reference photo into a print-ready 3D CAD model built for casting, and deliver finished high-resolution photorealistic visuals and on-body imagery.
Client Reference
Raw Reference Image
Any smartphone photo, sketch, or mood-board image with target finger size, stone count, and metal preferences. No CAD file needed to get started.
- Hand sketch or physical sample photo
- Target dimensions & stone specifications
- Confidential & protected under strict NDA
- Free feasibility review & confirmed quote within 24 hours
Print-Ready CAD
Production-Ready 3D CAD
Engineered in Rhino & Matrix to exact manufacturing tolerances. Fully watertight mesh ready for wax 3D printing, casting, and stone setting.
- 1 .3DM editable master + 1 .STL print file
- Dimension sheet & stone placement guide
- 1 or 2 revisions included to guarantee fit
- Guaranteed 100% agreement between CAD & renders
Master Product Presentation
Photorealistic CGI featuring 4 camera viewing angles, on-body lifestyle shot, and a 20-second 360° turntable spin video across all 3 precious metal finishes. Every asset produced from the single CAD model.
What we produce
CAD from sketch
Hand drawings or digital sketches turned into precise 3D geometry, built to your stated dimensions and finger or chain sizes.
CAD from photographs
Reverse-engineering an existing piece from clear images and measurements, for reproduction, resizing or redesign.
Print-ready preparation
Existing models checked and repaired for casting: closed meshes, correct wall thickness, seated stones, cast-safe supports.
Size and variant sets
A full size run from one master, with proportions adjusted correctly rather than scaled uniformly, which distorts settings.
Stone layout
Pavé, channel and bezel layouts calculated to your actual stone inventory, with a cutting list you can order against.
Technical drawings
Dimensioned production drawings and stone schedules to accompany the model, for your bench or your caster.
Files you receive for $12
| Deliverable | Format | Purpose & Details |
|---|---|---|
| Editable master | 1 .3DM file | Rhino and Matrix native. Fully editable for future design changes. |
| Print & casting file | 1 .STL file | Watertight, verified mesh resolution ready for 3D printing and casting. |
| Measurement image | 1 Dimension Sheet | Detailed measurement annotations and stone placement guide. |
| Revisions | 1 or 2 Included | Fine-tuning to ensure the model matches your specifications exactly. |
Order CAD & Rendering together for only $20! Save $4 on every design with our most popular Bundle Offer: get complete production CAD files (3DM + STL + measurement sheet) plus the full 3D rendering package (20-second 360° spin in 3 metal colors, 4 angles & on-body images) for just $20. View pricing & bundles.
Jewelry CAD FAQ
What do you need to start a CAD project?
A sketch, drawing or clear photographs, plus the key dimensions - ring size, overall measurements, and the stone sizes you intend to set. If you are unsure about any dimension, tell us the intent and we will propose something and confirm before building.
Can you work to my casting house's requirements?
Yes. Send us their specification for minimum wall thickness, sprue placement and mesh resolution and we will build to it. If you do not have one, we use conservative values that cast reliably in gold, silver and platinum.
Do I own the CAD file?
Yes. On final payment the model is yours outright, including the editable 3DM master. We do not retain rights to your designs, resell models or reuse them for other clients.
Can you resize an existing design?
Yes, and it should be done properly rather than by uniform scaling. Scaling a whole ring up distorts the setting and changes stone seats. We adjust the shank while holding the head and stone dimensions correct, which is what a full size run needs.
How long does a CAD model take?
Two to four business days for a straightforward ring or pendant. Complex pieces with detailed pavé, multiple components or articulated elements take longer, and we confirm the timeline at quote before starting.
From sketch to casting-ready file
Send a drawing and your measurements. We will tell you what is achievable, what it costs and how long it takes.
